E a s i - P i c o U s e r G u i d e
MAIN MENU
STATUS
AUDIO
MAIN MENU
When you first power the system up, the "Clear-Com Easi-PiCo" screen appears.
When you press the setup/enter knob, the main menu appears.
SYSTEM PORTS
P
N
Figure 1-27: Easi-PiCo System Ports Screen
SYSTEM PORTS (PORT STATUS)
Each rectangle on the System Ports menu represents one of the 16 possible "port"
connections in the system. A "port" connection is one of the RJ-45 connectors
on the PiCo's rear panel to which remote panels and interfaces are connected
with CAT-5 cable.
When a remote device is connected to a PiCo "port" the rectangle will first show
a chequered pattern to indicate communications activity, then will change to a
solid light when the connected device is online and communicating with the
matrix.
In addition, a letter or number will appear above each rectangle to indicate the
type of connection, as follows:
R
4
P
N
X
Table 1-1: Easi-PiCo System Port Types
GPI STATUS (Read only screen in Easi-PiCo)
You can connect an external logic device-such as an external foot switch, a
panel-mounted switch, or the logic output of some other device-to the "GP IN"
connector on the rear panel of the PiCo.
ROUTING CONFIGS
Figure 1-26: Easi-PiCo Main Menu
X X X X X X X X X X X X X X X X X X X X
Partyline/2-wire (CCI-22H)
4-wire audio (FOR-22H) or 4-wire direct
panel
4-wire network link
Port not in use
EXIT
SYSTEM
EXIT
2 5
