Maintenance work on the superstructure
8.5 Exhaust system with exhaust emission control
8.5.1
Checking
H
8.5.2
Consumable and
tools
Prerequisites
8 - 36

Checking the AdBlue tank level

The warning lamp for checking the AdBlue system and a display for the
AdBlue level in the tank is located on the side console in the crane cab.
The tank has a maximum filling volume of approx. 37.8 l (10 gal). Depending
on where the truck crane is used, it may be sensible to carry additional can-
isters of AdBlue.
•
Start the engine.
•
Check the AdBlue level in the tank via the display (1) in the crane cab;
à
Operating manual .
•
Refill the tank when the AdBlue level falls below one quarter (1/4) at the
very latest.
•
Check the warning lamp (1). The lamp lights up when the AdBlue tank is
empty or when a fault occurs in the AdBlue system.

Filling up with AdBlue

AdBlue
in litres (gal)
37.8 (10) DEF (Diesel Exhaust Fluid)
e.g. AdBlue .
– As required: 2 canisters of about 20 l each (5 gal);
– A service station with a filling pump for AdBlue can be used, or AdBlue
can be filled manually from canisters.
– The engine must not be running and must be secured against unauthor-
à
ised use; P. 2 - 3.
Specifications
Classification
3 302 577 en
D
GROVE part no.
03140555
à
P. 2 - 4.
Maintenance manual
GMK7450
