Graphic Display - btsr SMART MATRIX MTC Operating Manual

Graphic display

This function, which can be activated pressing the shortcut button
that indicates the yarn quantity currently measured by each sensor (percentage of target)
Press the graphics direct access button.
To select the various positions.
Machine side
Section
Number of highlighted sensor
Coordinates of highlighted sensor (indicated with
Percentage of target
Target of highlighted sensor (indicated with
Number of strokes on the highlighted sensor
Press one time to display the counter of targets and the
counter of broken yarns failures of the selected sensor.
Rotate to scroll the same information of the other sensors.
The CLR METER
counting on one or more sensors.
To select the desired device interval.
SMART MATRIX MTC
, allows you to display a screenshot
)
)
function allows you to reset the meter
Graphic display
