Position setting
This function allows you to set:
1. LDRUM: the drum length (development), i.e. the length of yarn that will be wound on the bobbin during
every stroke. The value may range between 1 mm and 5000 mm and it may be associated to all the
installed sensors, or you may want to assign different values to specific sensor ranges. Depending on
the set value, the system will automatically calculate the number of strokes needed to obtain the Target,
according to the following formula:
Number of strokes = Target x 1000
2. KANTIP: the correction factor in the yarn length calculation if a constant error due to a bobbin slippage
or to a different drum size is detected (KANTIP = Anti-pattern factor). To the measured value, it will be
possible to either add or subtract a percentage value ranging between –25.0% and +25.0%. In this case
the number of strokes needed to obtain the Target will be calculated according to the following formula:
Number of strokes = Target x 1000 +/- KANTIP.
LDRUM
LDRUM
SMART MATRIX MTC
Select the
POSITION SET
Select the first device and press one time to set the
LDRUM
value. Press again to set the
If there are many sensors, use the
move forward and backward 10 sensors a time.
Set the development value of cylinder (e.g.
LDRUM=1200 mm)
Press the
key to increase the value 10 mm a
time.
Press
to set the
LDRUM
confirm with
YES
Press
to copy the set
other sensors and confirm with
Position setting
POSITION SET
menu
item.
KANTIP
value.
e
keys to
default value and
LDRUM
value to all the
YES
2 - 37
