Style Loading

This function allows you to load, to the MTC sensors, one of the styles available in the database, or to
unload the style currently loaded in the sensors.
All the connected MTC sensors can be configured with the same parameters or, (to increase the system
flexibility) you may create multiple device groups, up to a maximum of 10 groups, configuring each group
with different parameters.
Style Loading
Select the STYLE LOAD
Once you have activated the
from main menu, choose the style you want to load
(e.g.. MTC1) and press LOAD.
Select the range of devices to be loaded with the
style (default: all).
LOAD to load the style.
"LOAD MTC STYLE"
then the display turns back to the
menu, with the new style loaded
If different styles have been loaded to different
devices, the diskette symbol (style loaded indication)
appears for 2 or more styles.
If on the same device two different styles are loaded,
the warning
appears.
SMART MATRIX MTC
menu item.
STYLE LOAD
appears for a few seconds and
STYLE LOAD
"STYLE OVERLAP CONTINUE?"
Style Loading
STYLE LOAD
function
2 - 35
