Signal Pin # Description
USB_SSTX0+ B23 Additional transmit signal differential pairs for the SuperSpeed
USB_SSTX0- B22 USB data path.
USB_SSTX1+ B26 Additional transmit signal differential pairs for the SuperSpeed
USB_SSTX1- B25 USB data path.
USB_SSRX0+ A23 Additional receive signal differential pairs for the SuperSpeed
USB_SSRX0- A22 USB data path.
USB_SSRX1+ A26 Additional receive signal differential pairs for the SuperSpeed
USB_SSRX1- A25 USB data path.
Table 21 LVDS Signal Descriptions
Signal Pin # Description
LVDS_A0+ A71 LVDS Channel A differential pair 0
eDP_TX2+ Embedded Display Port channel 0 differential pair 2
LVDS_A0- A72 LVDS Channel A differential pair 0
eDP_TX2- Embedded Display Port channel 0 differential pair 2
LVDS_A1+ A73 LVDS Channel A differential pair 1
eDP_TX1+ Embedded Display Port channel 0 differential pair 1
LVDS_A1- A74 LVDS Channel A differential pair 1
eDP_TX1- Embedded Display Port channel 0 differential pair 1
LVDS_A2+ A75 LVDS Channel A differential pair 2
eDP_TX0+ Embedded Display Port channel 0 differential pair 0
LVDS_A2- A76 LVDS Channel A differential pair 2
eDP_TX0- Embedded Display Port channel 0 differential pair 0
LVDS_A3+ A78 LVDS Channel A differential pair 3
LVDS_A3- A79 LVDS Channel A differential pair 3
LVDS_A_CK+ A81 LVDS Channel A differential clock
eDP_TX3+ Embedded Display Port channel 0 differential pair 3
LVDS_A_CK- A82 LVDS Channel A differential clock
eDP_TX3- Embedded Display Port channel 0 differential pair 3
LVDS_VDD_EN A77 Panel power enable
eDP_VDD_EN
LVDS_BKLT_EN B79 Panel backlight enable
eDP_BKLT_EN
LVDS_BKLT_CTRL B83 Panel backlight brightness control
eDP_BKLT_CTRL
LVDS_I2C_CK A83 DDC lines used for flat panel detection and control.
eDP_AUX+ Embedded Display Port AUX channel pair
LVDS_I2C_DAT A84 DDC lines used for flat panel detection and control.
eDP_AUX- Embedded Display Port AUX channel pair
Copyright © 2017 congatec AG
I/O PU/PD Comment
O USB-SS
O USB-SS
I USB-SS
I USB-SS
I/O PU/PD Comment
O LVDS LVDS (default)
O eDP Assembly option: eDP
O LVDS LVDS (default)
O eDP Assembly option: eDP
O LVDS LVDS (default)
O eDP Assembly option: eDP
O LVDS LVDS (default)
O eDP Assembly option: eDP
O LVDS LVDS (default)
O eDP Assembly option: eDP
O LVDS LVDS (default)
O eDP Assembly option: eDP
O LVDS
O LVDS
O LVDS LVDS (default)
O eDP Assembly option: eDP
O LVDS LVDS (default)
O eDP Assembly option: eDP
O 3.3V PD 100k LVDS (default)
Assembly option: eDP
O 3.3V PD 100k LVDS (default)
Assembly option: eDP
O 3.3V LVDS (default)
Assembly option: eDP
I/O 3.3V LVDS PU LVDS (default)
I/O eDP 2k2 3.3V Assembly option: eDP
I/O 3.3V LVDS PU LVDS (default)
I/O eDP 2k2 3.3V Assembly option: eDP
