Revision History
Revision Date (yyyy.mm.dd) Author Changes
0.1 2017.04.07
1.0 2017.09.21
1.1 2018.06.25
1.2 2018.08.21
1.3 2018.10.16
1.4 2019.01.18
1.5 2019.04.16
1.6 2020.01.07
1.7 2021.02.19
Copyright © 2017 congatec AG
BEU • Preliminary release
•
BEU Minor improvements throughout the document
• Updated section 2.2 "Supported Operating Systems", 2.4 "Supply Voltage Standard Power", 2.4.1 Electrical
Characteristics", 3 "Block Diagram", 5.7.3 "DVI-D", 5.8 "SD Card", 6.1.1 "eMMC 5.0", and 6.7 "Security Features"
•
Added inrush and maximum currents peaks paragraph to section 5.14 "Power Control"
• Added section 5.16 "MIPI CSI-2"
• Updated tables 7 "Power Consumption Values", 8 "CMOS Battery Power Consumption", 13 "COM Express Connector
Pinouts", 16 "Serial ATA Signal Descriptions", 18 "ExpressCard Support Pins Signal Descriptions", 19 "USB Signal
Descriptions", 20 "LVDS Signal Descriptions", 23 "DDI Signal Descriptions", 24 "DisplayPort (DP) Signal Descriptions",
25 "HDMI/DVI Signal Descriptions", 28 "Miscellaneous Signal Descriptions", 29 "Power and System Management Signal
Descriptions"
•
Added fully legacy UART 16550 compliant LPC controller as assembly option
• Added content to section 9 "System Resources"and 10 "BIOS Setup Description"
•
BEU Added errata as a document to read in the preface section
• Updated "Electrostatic Sensitive Device" information on page 3
• Updated security features in table 4 "Feature Summary"
• Removed Android from supported OS in section 2.2 "Supported Operating Systems"
• Added EFT caution to section 5.4.1 "USB 2.0"
• Updated section 5.9 "General Purpose Serial Interface (UART)"
•
BEU Minor improvements throughout the document
BEU • Corrected commercial operating temperature in section 2.7 "Environmental Specifications"
• Corrected pin A83 and A84 description in table 20 "LVDS Signal Descriptions"
• Added voltages and BIOS revision information to table 7 "Power Consumption Values"
BEU • Corrected image in section 2.3 "Mechanical Dimensions"
BEU • Corrected image in section 2.3 "Mechanical Dimensions"
BEU • Removed support for IoT 32-bit OS in section 2.2 " Supported Operating Systems"
•
Updated section 4 "Cooling Solutions"
• Updated reference to power supply design guide in section 5.14 "Power Control"
• Updated section 10.3 "Updating the BIOS"
•
Updated section 10.4 "Supported Flash Devices"
• Added note about pulse width to several signals in table 29
• Added reference to BIOS Setup Description application note in section 10 "BIOS Setup Description"
•
Updated section 11 "Industry Specifications"
BEU • Corrected the storage temperature for industrial variants in section 2.7 "Environmental Specifications"
