NETGEAR WAX204 User Manual page 50

WiFi 6 AX1800 Dual Band Wireless Access Point WAX204
Use Auto Detect for an IPv6 Internet connection [router mode] on page 44). The
access point uses the 6rd option information to establish the 6rd connection.
• Manual mode. Select 6rd Tunnel. If the access point receives option 212, the fields
are automatically completed. Otherwise, you must enter the 6rd settings.
To set up an IPv6 6rd Internet connection:
1. Launch a web browser from a computer or mobile device that is connected to the
access point network.
2. Enter http//www.routerlogin.net in the address field.
If you are not connected to the access point network but to the same network as the
access point, enter the IP address that is assigned to the access point. If you do not
know the IP address, see Find the IP address of the access point when you cannot
use routerlogin.net on page 27.
A login window displays.
If your browser does not display the login window but displays a security message
and does not let you proceed, see Log in to the access point after initial setup on
page 30.
3. Enter the access point local device password.
The local device password is the one that you specified. The local device password
is case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Advanced Setup > IPv6.
The IPv6 page displays.
5. From the Internet Connection Type menu, select 6rd Tunnel.
The page adjusts. The access point automatically detects the information in the
following sections:
• 6rd (IPv6 Rapid Development) Configuration. The access point detects the
service provider's IPv4 network and attempts to establish an IPv6 6rd tunnel
connection. If the IPv4 network returns 6rd parameters to the access point, the
page adjusts to display the correct settings in this section.
Note: If the access point does not automatically receive the 6rd parameters, you
might need to enter them manually.
• Router's IPv6 Address on LAN. This field shows the IPv6 address that is acquired
for the access point's LAN interface. The number after the slash (/) is the length
of the prefix, which is also indicated by the underline (_) under the IPv6 address.
If no address is acquired, the field displays Not Available.
Manually Set Up Internet
Settings
50 User Manual
