Features

1 Features
•
STM32L4R9AII6 Arm
640 Kbytes of RAM in a UFBGA169 package
•
1.2" 390x390 pixels MIPI DSI
•
4.3" 480x272 pixels TFT LCD with RGB mode
•
Two ST-MEMS digital microphones
•
8-Gbyte microSD™ card bundled
•
16-Mbit (1 M x 16 bit) SRAM device
•
128-Mbit (8 M x 16 bit) NOR Flash memory device
•
512-Mbit Octo-SPI Flash memory device with double transfer rate (DTR) support
•
64-Mbit Octo-SPI SRAM memory device with HyperBus interface support
•
EEPROM supporting 1 MHz I²C-bus communication speed
•
Reset and wake-up/tamper buttons
•
Joystick with four-way controller and selector
•
Touch-sensing button
•
Light-dependent resistor (LDR)
•
Potentiometer
•
Coin battery cell for power backup
•
Board connectors:
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
•
Flexible power-supply options: power jack, ST-LINK/V2-1 USB connector,
a. Arm is a registered trademark of Arm Limited (or its subsidiaries) in the US and/or elsewhere.
8/72
®(a)
-based microcontroller with 2 Mbytes of Flash memory and
Two jack outputs for a stereo audio headphone with independent content
Slot for microSD™ card supporting SD and SDHC
TFT LCD standard connector
MIPI DSI SM display standard connector
EXT_I2C connector supports I²C bus
RS-232 port configurable for communication or MCU flashing
USB OTG FS Micro-AB port
CAN 2.0A/B-compliant port
Connector for ADC input and DAC output
JTAG/SWD connector
ETM trace debug connector
User interface through USB virtual COM port
Embedded ST-LINK/V2-1 debug and flashing facility
TAG connector
STDC14 connector
PMOD connector
Extension connector for the daughterboard
Motor-control connector on the daughterboard
SM round LCD
