Idd Measurement; Dsi Display (Mipi) Connector; Table 19. Idd Measurement Related Jumper Setting - ST STM32L4R9I-EVAL User Manual

UM2248
Pin number
of MFX
18
19
20
26
27
28
29
30
31
32
33
39
40
6.28

IDD measurement

STM32L4R9AII6 has a built-in circuit allowing to measure its current consumption (IDD) in
Run and Low-power modes, except for Shutdown mode. It is strongly recommended that
the MCU supply voltage (VDD_MCU line) does not exceed 3.3 V. This is because there are
components on STM32L4R9I-EVAL supplied from 3.3 V that communicate with the MCU
through I/O ports. Voltage exceeding 3.3 V on the MCU output port may inject current into
3.3 V-supplied peripheric I/Os and false the MCU current consumption measurement.
Table 19
s
Jumper
JP4
6.29

DSI display (MIPI) connector

The CN16 connector is designed to connect a DSI display daughterboard. MB1314
daughterboard is available to mount on the STM32L4R9I-EVAL board.
assignment of CN16 and STM32L4R9AII6 terminals.
Table 18. MFX signals (continued)
Pin name
MFX functions
of MFX
PB0 MFX_GPIO0
PB1 MFX_GPIO1
PB2 MFX_GPIO2
PB13 MFX_GPIO13
PB14 MFX_GPIO14
PB15 MFX_GPIO15
PA8 MFX_GPIO8
PA9 MFX_GPIO9
PA10 MFX_GPIO10
PA11 MFX_GPIO11
PA12 MFX_GPIO12
PB3 MFX_GPIO3
PB4 MFX_GPIO4
shows the setting of jumpers associated with the IDD measurement on the board.

Table 19. IDD measurement related jumper setting

Setting
1 2 3
1 2 3
Function of
STM32L4R9AII6
JOY_SEL
JOY_DOWN
JOY_LEFT
-
-
-
EXT_RESET
DSI_RST
-
LCD_DISP
LCD_RST
JOY_RIGHT
JOY_UP
Default setting.
STM32L4R9AII6 has a built-in circuit allowing to measure its
current consumption.
IDD measurement is not available, bypass mode only for
STM32L4R9AII6 VDD_MCU power supply.
