Table 23. Pin function description of the CN1 MB1314 board connector (continued)
Pin number
23
25
27
29
31
33
35
37
39
41
43
45
47
49
51
53
55
57
59
Warning:
6.33

MB1315 TFT LCD board

MB1315 is the TFT LCD daughterboard supporting RGB mode, available to mount on the
STM32L4R9I-EVAL board via CN1 connector.
The 4.3" TFT LCD uses LCD RK043FN48H-CT672B with a capacitive touch panel which only
supports 3.3 V power and interface. So a level shifter SN74LVC16T245DGGR is requested on
TFT RGB LCD daughterboard to support a wide power supply range.
function description of the CN1 MB1315 board connector.
Description
BLVDD (5 V)
-
BLGND
BLGND
-
-
RFU
RFU
RFU
-
SWIRE
RFU
RFU
DSI_TE
-
DSI_BL_CTRL
-
DSI_RST
-
Permanent Image sticking may occur if AMOLED displays the
same image for an extended time.
UM2248 Rev 4
Hardware layout and configuration
Pin number
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52
54
56
58
60
Table 24
Description
RFU
RFU
RFU
-
-
-
3.3 V
VDD
I2C_SDA
-
I2C_SCL
-
-
-
-
-
-
-
RFU
shows the pin
