Hardware layout and configuration
6.30.1

Limitations

The TFT LCD module connector supports RGB mode or FMC mode only at the same time.
The signal INT is used both for TFT LCD and DSI display connectors. When RGB mode
TFT LCD is used, STM32L4R9AII6 cannot access onboard SRAM and NOR Flash memory.
6.31

PMOD connector

The P1 PMOD-standard connector is available on the STM32L4R9I-EVAL board to support
flexibility in small form factor applications. The PMOD connector implements the PMOD
type 2A and 4A on the STM32L4R9I-EVAL board.
Pin number
1
2
3
4
5
6
6.32

MB1314 DSI display board

MB1314 is the DSI display daughterboard that is available to mount on the STM32L4R9I-
EVAL board via CN1 connector. GVO IEG1120TB103GF-001 is selected for round LCD with
one data lane, 390x390 resolution, 24 bpp with capacitive touch panel (FocalTech FT3x67
driver). Table 23

Table 23. Pin function description of the CN1 MB1314 board connector

Pin number
1
3
5
7
9
11
13
15
17
19
21
46/72

Table 22. P1 PMOD connector

Description
SS/CTS (PI0/PB13)
MOSI/TXD (PI3/PG7)
MISO/RXD (PI2/PG8)
SCK/RTS (PI1/PB12)
GND
3.3 V
shows the pin function description of the CN1 MB1314 board connector.
Description
GND
DSI_CK_P
DSI_CK_N
GND
DSI_D0_P
DSI_D0_N
GND
RFU
RFU
GND
BLVDD (5 V)
UM2248 Rev 4
Pin number
7
8
9
10
11
12
Pin number
2
4
6
8
10
12
14
16
18
20
22
UM2248
Description
INT (PG13)
RESET (PB14)
-
-
GND
3.3 V
Description
-
DSI_INT
GND
RFU
RFU
GND
RFU
RFU
GND
-
RFU
