CN7 RS232 connector

Pin number
1
2
3
4
5
7.7 CN8 microSD™ connector

Figure 15. RS232 D-sub male connector (front view)

Table 33. RS232 D-sub male connector

Description
NC
RS232_RX (PG8)
RS232_TX (PG7)
NC
GND
Figure 16. CN8 microSD™ connector (top view)
UM2248 Rev 4
Pin
number
6
7 RS232_RTS (PB12)
8 RS232_CTS (PB13)
9
-
Connectors
MS30720V1
Description
NC
NC
-
