Table A-7 Variable Spd Contents - SMART Embedded Computing MVME7100 Programmer's Reference Manual

Programmable Configuration Data
Table A-6
Value
99 (0x63)
:
127 (0x7F)
NOTES:
1. This will typically be programmed as 128 bytes.
2. This will typically be programmed as 256 bytes.
3. From data sheet.
4. High order bit is self-refresh flag. If set to 1, the assembly supports self refresh.
5. Reserved.
Table A-7
Offset
00 (0x00)
01 (0x01)
02 (0x02)
03 (0x03)
04 (0x04)
05 (0x05)
06 (0x06)
07 (0x07)
08 (0x08)
78
Static SPD Contents (continued)
Offset Description
00 Manufacturer's Specific Data.
Refer to Note
:
00
Variable SPD Contents
Value Description
80 Number of Serial PD Bytes written during module production: 0x80 =
128 bytes.
Refer to Note
08 Total Number of Bytes in Serial PD Device: 0x08 = 256 bytes.
Refer to Note
08 Fundamental Memory Type (FPM, EDO, SDRAM): 0x08 = DDR2
SDRAM
0E Number of Row Addresses on this assembly: 0x0E = A0-A13
0A Number of Column Addresses on this assembly: 0x0A = A0-A9
00 Number of DIMM Banks: 0x00 = one bank
48 Data Width of this assembly: 0x48 = 72 bits
00 Reserved
05 Voltage Interface Level of this assembly: 0x05 = SSTL 1.8 V
