Table A-4
Offset
(HEX)
70
71
72
73
74
75
76
77
78
79
7A
7B
7C
7D
7E
7F
80
81
82
83
84
85
MVME7100 Single Board Computer Programmer's Reference (6806800E82C)
Static VPD Contents (continued)
Data (HEX) Field Type
0A BINARY
04 BINARY
xx BINARY
xx
xx
xx
0B BINARY
0C BINARY
00 BINARY
01
7E BINARY
23
10 BINARY
02 BINARY
01 BINARY
20 BINARY
20 BINARY
01 BINARY
6E BINARY
09 BINARY
0B BINARY
0C BINARY
Programmable Configuration Data
Description
EPROM CRC
When computing the CRC this field (4 bytes) is set to
zero. This CRC only covers the range as Integer (4-
Vital Product Data CRC Calculation
byte). Refer to
on page 61
.
Note:
Lower CRC byte for the calculation of CRC = 0x00
Upper CRC byte for the calculation of CRC = 0x1FF
# of bytes
** CRC to be filled in
Bank 1 Flash Memory Configuration Packet
# of bytes
Vendor Identifier
Device Identifier
Single device width in bits
Number of devices or sockets present
Number of interleave columns
Column width in bits
Minimum write/erase data width in bits
Flash bank number
Flash access speed in nanoseconds: 0x6E = 110 ns
Total bank size [(1<<n)*256K bytes]: 0x09 = 128 MB
Bank 2 Flash Memory Configuration Packet
# of bytes
