A.11 SPD Contents for MVME7100 Boards

The following tables describe the static as well as variable SPD data to be programmed into
U50 and U51.
Table A-6
Value
00 (0x00)
01 (0x01)
02 (0x02)
03 (0x03)
04 (0x04)
05 (0x05)
06 (0x06)
07 (0x07)
08 (0x08)
09 (0x09)
10 (0x0A)
11 (0x0B)
12 (0x0C)
13 (0x0D)
14 (0x0E)
15 (0x0F)
16 (0x10)
MVME7100 Single Board Computer Programmer's Reference (6806800E82C)
Static SPD Contents
Offset Description
80 Number of Serial PD Bytes written during module production: 0x80 =
128 bytes.
Refer to Note
08 Total Number of Bytes in Serial PD Device: 0x08 = 256 bytes.
Refer to Note
08 Fundamental Memory Type (FPM, EDO, SDRAM): 0x08 = DDR2
SDRAM
0E Number of Row Addresses on this assembly: 0x0E = A0-A13
0A Number of Column Addresses on this assembly: 0x0A = A0-A9
00 Number of DIMM Banks: 0x00 = one bank
48 Data Width of this assembly: 0x48 = 72 bits
00 Reserved
05 Voltage Interface Level of this assembly: 0x05 = SSTL 1.8 V
30 SDRAM Cycle time at Maximum Supported CAS Latency (CL), CL=X:
0x30 = 3.0ns.
Refer to Note
45 SDRAM Access time from Clock at Maximum Supported CAS Latency
(CL), CL=X: 0x45 = 0.45ns.
Refer to Note
02 DIMM configuration type (Non-parity, Parity or ECC): 0x02 = ECC
82 Refresh Rate/Type: 0x82 = 7.8us.
Refer to Notes 3 and 4.
08 Primary SDRAM Width: 0x08 = 8 bits
08 Error Checking SDRAM Width: 0x08 = 8 bits
00 Reserved
0C SDRAM Device Attributes - Burst Lengths Supported: 0x0C = 4, and
8 burst lengths
Programmable Configuration Data
1
.
2
.
3
.
3
.
73
