Table 4-1
MC864xD
Signal
TSEC3_TX
D[3]
TSEC2_TX
D[0:3]
TSEC1_TX
D[0]
MVME7100 Single Board Computer Programmer's Reference (6806800E82C)
MC864xD POR Configuration Settings (continued)
Default
Select
POR
Option
Settings
Switch 1
1111(no
option for
Resistors
pull-
downs)
1 (no
option pull-
Resistor
down)
Description State of Bit vs Function1
Core 1 Low
0
Memory
offset
1
0000
0001
0010
0100
Boot ROM
location
0101
1101
1110
1111
0
Alternate
Boot Vector
Location
1
Programming Details
Real address A in range 0 to 256
MB-1 translated to Address A +
256MB
sys addr = real addr
PCI Express 1
PCI Express 2
Serial RapidIO
DDR Memory Controller 1
DDR Memory Controller 2
Local Bus GPCM - 8-bit ROM
Local Bus GPCM - 16
Local Bus GPCM -32 -bit ROM
PCI-E 1 outbound ATMU window
1 is enabled
Boot vector fetched from default
boot ROM location
