SMART Embedded Computing MVME7100 Programmer's Reference Manual page 48

Programming Details
Table 4-1
MC864xD
Signal
TSEC4_TX
D[0:3]
46
MC864xD POR Configuration Settings (continued)
Default
Select
POR
Option
Settings
1111
(no options
Resistors
for pull-
downs)
MVME7100 Single Board Computer Programmer's Reference (6806800E82C)
Description State of Bit vs Function1
0010
0011
0101
0110
0111
I/O Port
Selection
1001
1010
1011
1110
1111
Programming Details
SerDes1: x1/x2/x4/x8 PCIE, 100
MHz ref clkSerDes2: disabled
SerDes1: x1/x2/x4/x8 PCIE, 100
MHz ref clk
SerDes2: x1/x2/x4/x8 PCIE, 100
MHz ref clk
SerDes1: x1/x2/x4/x8 PCIE, 100
MHz ref clk
SerDes2: x4 Serial RapidIO
SerDes1: x1/x2/x4/x8 PCIE, 100
MHz ref clk
SerDes2: x4 Serial RapidIO
SerDes1: x1/x2/x4/x8 PCIE, 100
MHz ref clk
SerDes2: x4 Serial RapidIO
SerDes1: disabled
SerDes2: x4 Serial RapidIO
SerDes1: disabled
SerDes2: x4 Serial RapidIO
SerDes1: disabled
SerDes2: x4 Serial RapidIO
SerDes1: disabled
SerDes2: x1/x2/x4/x8 PCIE
SerDes1: x1/x2/x4/x8 PCI-E, 100
MHz ref clk
SerDes2: x1/x2/x4/x8 PCI-E, 100
MHz ref clk
