SMART Embedded Computing MVME7100 Programmer's Reference Manual page 17

Table 1-1
Function
Timers
Watchdog Timer
VME Interface
Form Factor
Miscellaneous
Software Support
MVME7100 Single Board Computer Programmer's Reference (6806800E82C)
Features List (continued)
Features
Four 32-bit MC864xD timers
Four 32-bit timers in a PLD
One watchdog timer in PLD
VME64 (ANSI/VITA 1-1994) compliant (3 row backplane 96-pin VME
connector)
VME64 Extensions (ANSI/VITA 1.1-1997) compliant (5 row
backplane 160-pin VME connector)
2eSST (ANSI/VITA 1.5-2003) compliant
Two five-row P1 and P2 backplane connectors
One Tsi148 VMEbus controller
Standard 6U VME, one slot
One front panel RESET/ABORT switch
Six front panel status indicators:
Two 10/100/1000 Ethernet link/speed and activity (4 total)
Board fail
User S/W controlled LED
Planar status indicators
One standard 16-pin JTAG/COP header
Boundary scan support
Switches for VME geographical addressing in a three-row backplane
VxWorks OS support
Linux OS support
Introduction
