Programming Details

4.1

Overview

This chapter includes additional programming information for the MVME7100. Items
discussed include:
MC864xD Reset Configuration on page 43
MC864xD Interrupt Controller on page 49
Local Bus Controller Chip Select Assignments on page 50
I2C Device Addresses on page 50
User Configuration EEPROM on page 51
VPD EEPROM on page 51
RTM VPD EEPROM on page 52
Ethernet PHY Address on page 52
Flash Memory on page 53
PCI/PCI-X Configuration on page 54
PCI IDSEL and Interrupt Definition on page 54
PCI Arbitration Assignments on page 55
LBC Timing Parameters on page 56
Other Software Considerations on page 56
Clock Distribution on page 57
4.2

MC864xD Reset Configuration

The MVME7100 supports the power-on reset (POR) pin sampling method for processor
reset configuration. The states of the various configuration pins on the processor are
sampled when reset is deasserted to determine the desired operating modes.
Combinations of pull-up and pull-down resistors are used to set the options. Some options
are fixed and some are selectable at build time by installing the proper pull-up/pull-down
MVME7100 Single Board Computer Programmer's Reference (6806800E82C)
Chapter 4
43
