Introduction
Table 1-1
Function
2
I C
NOR Flash
NAND Flash
NVRAM
PCI-E
I/O
USB
Ethernet
Serial Interface
14
Features List (continued)
Features
One 8KB VPD serial EEPROM
Two 64KB user configuration serial EEPROMs
One Real Time Clock (RTC) with removable battery
Dual temperature sensor
Two SPDs for memory
Connection to XMCspan and RTM
128 MB soldered flash with two alternate 1 MB boot sectors
selectable via hardware switch
H/W switch or S/W bit write protection for entire logical bank
Up to two devices available:
4GB - 1 device
8GB - 1 device
16GB - 2 devices
One 512KB MRAM extended temperature range (-40°C to
105°C/-40°F to 221°F)
Two 64KB serial EEPROMs
8X Port to XMC Expansion
8X Port to 5 Port PCI Express switch
One front panel mini DB-9 connector for front I/O: one serial channel
Two front panel RJ-45 connectors with integrated LEDs for front I/O:
two 10/100/1000 Ethernet channels
One front panel USB Type A upright receptacle for front I/O: one USB
2.0 channel
PMC site 1 front I/O and rear P2 I/O
PMC site 2 front I/O
One four-channel USB 2.0 controller: one channel for front panel I/O
Four 10/100/1000 MC864xD Ethernet channels: two front panel
Ethernet connectors and two channels for rear P2 I/O
One 16550-compatible, 9.6 to 115.2 Kbaud, MC864xD,
asynchronous serial channel: one channel for front panel I/O
One quad UART (QUART) controller to provide four
16550-compatible, 9.6 to 115.2 Kbaud, asynchronous serial
channels: four channels for rear P2 I/O
