Programmable Configuration Data
Table A-3
SPD Byte Address
61 (0x3D)
62 (0x3E)
Decimal Total
Divide by 256
Remainder
Convert to binary
63(0x3F)(Checksum)

A.10 VPD Contents for MVME7100 Boards

The following tables describe the VPD data to be programmed into U49.
only the static VPD data and
information is subject to change (under authority of an engineering change order). If a
difference is noted between any of these tables and your board, please contact your
support representative to determine which is accurate.
Table A-4
Offset
(HEX)
00
01
02
03
04
05
06
07
08
09
0A
0B
64
Checksum Calculation Example (continued)
Serial PD
0000 0000
0000 0000
-
-
-
0010 0010
0010 0010
Table A-5
Static VPD Contents
Data (HEX) Field Type
45 ASCII
4D
45
52
53
4F
4E
20
02 BINARY
00
0F BINARY
04 BINARY
MVME7100 Single Board Computer Programmer's Reference (6806800E82C)
Programmable Configuration Data
>
>
-
-
-
<
-
contains only the variable VPD data. This
Description
Eye-Catcher ("SMART EC") Note: Lowest CRC byte
for the calculation of CRC.
Size of VPD area in bytes. The size is viewed as
logical; it is not the size of the EEPROM. 512 bytes in
this VPD architecture
VPD Revision Packet
# of Bytes
Convert to Decimal
+ 0
+ 0
290
1
34
34
Table A-4 contains
