ARMS Error Messages

Error LCD Display
Code
E04001
E04002
E04003
E04004
E04005
E04006
E04007
E04008
E04009
E04010
E04011
E04012
E04013
CE6000-UM-251-9370
Cause
Tilt to adjust with AXIS
ALIGNMENT is too large.
It is over the setting range of the
distance adjust.
Failed to adjust the sensor level.
It is over the setting range of the
distance adjust.
Could not scan the registration
marks.
Amount of data has exceeded the
I/O buffer size for the segment
area registration mark.
Test pattern plotting position is not
within the plotting area for sensor
position adjustment.
Media end was detected while
detecting the registration mark.
It has exceeded detection area
while detecting the registration
mark.
It has exceeded detection area
while detecting the registration
mark.
It has exceeded detection area
while detecting the registration
mark.
It has exceeded detection area
while detecting the registration
mark.
It has exceeded detection area
while detecting the registration
mark.
9-7
9 TROUBLESHOOTING
Solution
Reload the media.
Reset to smaller value.
This media cannot be used.
Reset to smaller value.
Check the registration scan
position.
Decrease the data size.
Move the media toward center
and plot the test pattern.
Check the media. Check the print
position of the registration mark.
Check the media. Check the print
position of the registration mark.
Check the media. Check the print
position of the registration mark.
Check the media. Check the print
position of the registration mark.
Check the media. Check the print
position of the registration mark.
Check the media. Check the print
position of the registration mark.
