Pen Block Ce6000-120Ap - GRAPHTEC CE6000 Series Service Manual

10.8 Pen Block CE6000-120AP

No. Part No.
1 U792600726 Pen Block Assy, CE6000-120AP
2 U621583520 Pen Block Cover
3 U621353011
4 U621603101
5 U380265311
6 U621583450 Encoder Strip
7 U682157140
U621603111
8 U621583460 Guide Shaft
U621353000 Linear bearing & Shaft
9 U561080005 Pen Encoder, HEDS-9720#P50
U682157103
10
U561450062 Capacitor, RPEF11H104Z2P1A0
11 U772159880 2 Pen Holder Assy, CE6
12 U621583472
13 U621583442 Cable Guide
14 U621589350 Bearing, L-730ZZMTHP5
15 U621583420 BR Plate
16 U621583281
U792600703 Push Roller Sensor Board, CE6000
17
U792600803 Push Roller Sensor Board, CE6000
18 U692157366 Flexible Cable, FFC908206F
19 U621583302 Collar, Y Slider bottom Center
20 U621583390 BR Roller, Y Slider, R1240KK1MTRP5
21 U621583201
22 U621583331 Y Belt Stopper
23 U621583291 Y Slider Tension Bracket
24 U692157347
25 U562500142 Core, FSRC200120RTB00T
26 U621583381 Clamper, FPC
U792600702 Pen Relay Board, CE6000
27
U792600802 Pen Relay Board, CE6000
28 U772159890 2 Pen Station Assy, CE6
29 U621583800 2 Pen Station Bracket
