GRAPHTEC CE6000 Series Service Manual page 9

CE6000-120AP
Item
CPU
Configuration
Drive system
Maximum cutting area
Guaranteed precision cutting area
Mountable media width
Available roll media core diameter
Available roll media outer diameter Maximum: 200 mm
Available roll media weight
Number of push roller
Maximum cutting speed
Specifiable cutting speeds (cm/s)
Cutting Pressure
Minimum character size
Mechanical resolution
Programmable resolution
Repeatability accuracy
No. of pens mountable
Compatible cutter type
Compatible pen type
Interfaces
Buffer capacity
Command modes
Display panel
Rated power supply
Power consumption
Operating environment
Conditions for guaranteed precision 16°C to 32°C, 35% to 70% RH (Non-condensing)
External dimensions
(W x D x H)
Weight
*1: Varies depending on the type of Graphtec-authorized film and the cutting conditions
*2: The accuracy of minimum media width is when the push rollers are set to 5 mm from both edges of media.
*3: HP-GL TM is a registered trademark of Hewlett-Packard Company.
CE6000-UM-251-9370
32-bits CPU
Grit rolling
Digital servo
1190 mm x 50 m
1190 mm x 3 m
*1
Minimum: 594 mm
*2
Maximum: 1220 mm
3 inch
Less than 20 kg
5
600 mm/s
(in all directions)
1–10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60 cm/s
0.2 to 4.4 N
(20 gf to 450 gf) (38 steps)
5 mm (0.197 in) for alphanumeric Helvetica med. Font
0.005 mm
GP-GL: 0.1/0.05/0.025/0.01 mm; HP-GLTM
Max. 0.1 mm/in unit of 2 m (Designated file and cutting condition)
*1
2 pens
Supersteel cutter blades
Water-based fiber-tip pens and oil-based ballpoint pen
RS-232C/USB (Full Speed)
2 MB
GP-GL, HP-GL
Liquid crystal graphic display (240dot x 128dot)
100 to 120, 200 to 240 V AC, 50/60 Hz
100 VA
10°C to 35°C, 35% to 75% RH (Non-condensing)
Approx.
1575 x 1200 x 1250 mm (Including stand)
46 kg (Including stand)
CE6000-120AP
*3
1-2
1 INTRODUCTION
: 0.025 mm
*3
