Daily Operation - Lightspeed Redcat Access LSRCA 1881 User Manual

DAILY OPERATION

INSTRUCTIONS
12 1
11 2
10 3
9
4
8 5
7 6
1. At start of day, remove the microphone from the cradle charger
and put on.
• The microphone will default to the Mute position, the status will
turn to red.
• Place the microphone around your neck.
• Press the power/mute button, the status will turn blue,
indicating the microphone is active and ready to use.
• Adjust volume with the UP/DOWN buttons if necessary.
• If Flexmike needs to be powered down for some time, press and
hold the power button. To power Flexmike again, press and
hold the power button until the blue light begins to blink.
2. Private conversations.
• Mute the Flexmike during private conversations by momentarily
pressing the power button. When muted, the blue light turns
solid red.
• When conversation is over, momentarily press the power button
again to unmute the Flexmike.
3. End of day.
• Remove the Flexmike from around your neck.
• Place the Flexmike into the charging cradle and ensure the
power button is glowing red and the Mic status light is glowing
blue.
• The Flexmike will stay powered on during charging, but will
automatically be muted.
• It is not necessary to turn off Redcat. If you do want to power
it down, press the power button on side of Redcat. If Redcat
Access is powered down, then when Flexmike is removed
from charging the next day, it will automatically power on the
Redcat.
• If Redcat has the optional battery pack, see page 31 for Daily
Use instructions.
www.hearandlearn.com.au
Redcat Access is part of the
Offices Australia wide (03)93709355
www.hearandlearn.com.au technology family.
Power /
Mute
REGISTER
AUDIO IN
MIN
MAX
AUDIO
(ALD) OUT
MIN
MAX
ON/OFF
DC INPUT
24V/1.75A
23
