8.6

Performance Control

Select the 'Performance Control' submenu from the main setup menu and press enter or press the related letter in front of the menu to enter
the 'Performance Control' Setup screen. The menu is used for setting system clocks.
Feature
System Clock Mode
CPU Clock Speed
Note
congatec strongly recommends that when using the 'Manual Settings' option the 'CPU Clock Speed' should be set to the default value, which
is 500MHz. If an alternative setting for the 'CPU Clock Speed' must be used then it's recommended that this setting be extensively evaluated
in conjunction with the complete system.
Copyright © 2006 congatec AG
Options Description
Hardware Strapping Select if system clocks should be determined by manual settings
Manual Settings or by hardware bootup straps.
333 Mhz Set the CPU clock speed.
366 Mhz Hardware Strapping = CPU Clock Speed: 400MHz
400 Mhz
433 Mhz
466 Mhz
500 MHz
