BIOS Setup Description

10.1

The BIOS setup menu shows the features and options supported in the congatec BIOS. To access and navigate the BIOS setup menu, press

the <DEL> or <F2> key during POST.

The right frame displays the key legend. Above the key legend is an area reserved for text messages. These text messages explain the options

and the possible impacts when changing the selected option in the left frame.

10.2

The BIOS displays the BIOS project name and the revision code during POST, and on the main setup screen. The initial production BIOS for

conga-TCA5 is identified as TCA50R1xx, where:

• R is the identifier for a BIOS ROM file,

• 1 is the so called feature number and

• xx is the major and minor revision number.

The TCA50 binary size is 8 MB.

10.3

OEMs often use BIOS updates to correct platform issues discovered after the board has been shipped or when new features are added to the

BIOS. The conga-TCA5 uses a congatec/AMI AptioEFI firmware, which is stored in an onboard flash ROM chip and can be updated using the

congatec System Utility. The utility has four versions—DOS based command line, Win32 command line, Win32 GUI, and Linux version.

For more information about "Updating the BIOS" refer to the user's guide for the congatec System Utility "CGUTLm1x.pdf" on the congatec

website at www.congatec.com.

TA50m10

70/72
