HARDWARE OVERVIEW
2.3
Collimator Mount
2.3.1
Overview
Background
The Collimator Mount, in conjunction with various conical collimators, supplements the internal
Linac X-Y jaws to shape the beam with steep-dose gradients for stereotactic radiosurgery/
radiotherapy treatments.
Components (Shown: Mount for Varian Linacs)
No.
Hardware User Guide Rev. 4.9 RT / RS Stereotactic Hardware
④
③
②
①
Component
①
Collimator
②
Fixation ring
③
Fixation screws
④
Enclosure
⑤
Front screw tab
⑤
Figure 11
③
33
