IMMOBILIZATION HARDWARE
How to Mold the Top Mask
Steps
Hardware User Guide Rev. 4.9 RT / RS Stereotactic Hardware
1. Remove the clips from the vertical posts.
2. Place the top mask (④ on Figure 28) in the water bath until it becomes transparent.
3. Remove the mask from the bath and place on a towel to dry.
Before proceeding, test the temperature of the softened mask to ensure the patient's
4.
comfort.
Place the mask centrally over the patient's face ensuring that the curve in the mask is
5.
placed towards the patient's mouth.
6. Stretch the mask carefully and evenly towards the vertical posts.
7. Snap the mask onto the vertical posts and secure it with the 2 mm clips.
Gently contour the mask onto the patient's face. Make sure that the sides attached to
8.
the vertical posts are also molded to fit onto the patients face.
Figure 34
