Collimator Mount
2.3.4

Collimator Mount Siemens with Coded Plug

General Information
The Collimator Mount Siemens with coded plug supports the Siemens accessory code ST5VAR.
The linac X-Y jaw field is thereby restricted to a maximum of 5.3cm x 5.3cm.
Components
No.
①
②
③
④
⑤
⑥
36
② ①
③
Component
Collimator
Fixation ring
Enclosure
Fixation screws
Bevelled corner
Coded plug
⑤
④
Figure 12
Hardware User Guide Rev. 4.9 RT / RS Stereotactic Hardware
⑥
