Fader Sections
The following diagram shows the parameters of the master routing processing area
copied through scenes.
1
2
Item
1
2
3
4
5
6
7
8
Appendix P: Parameters Copied Through Scenes
input channel
overview in GUI
channel strip
4
3
Control
SIS switch
Panning control knobs
Fader
MUTE switch
B switch
bus trim control knob
delay control knob
Field
Masters processing
area in GUI
channel strip
6
1
2
Parameter
Spatial imaging system on/off
Surround panning (includes all surround sound
parameters)
Level
Mute on/off
Solo B in/out
Bus trim level
Delay time
Channel colour
Insert and
configuration
processing area in
GUI channel strip
8
6
4
5
7
3
