Digital system inputs and outputs
System connector
N+1 connector
DL451 I/O Box (option)
Analogue inputs
Connector
A/D converter
Analogue outputs
Connector
D/A converter
Digital inputs
Connector
Sample rates
Bypass
Digital outputs
Connector
Sample rates
Bypass
Word length
MIDI and GPIO
MIDI connector
GPIO IN connector
GPIO OUT connector
Digital system inputs and outputs
System connector
Duplicate connector
Appendix B: Technical Specification
3 x AES50 (24 channels of bi-directional digital
audio) on EtherCon® XLR
1 x AES50 (24 channels of bi-directional digital
audio) on EtherCon® XLR providing redundant back
up
3-pin XLR balanced
24-bit, 96k and 128 times over sampling
3-pin XLR balanced
24-bit, 96k and 128 times over sampling
AES3 (two channels of digital audio) on 3-pin XLR
Accepts any frequency between 32k to 96k
Sample rate converter can be bypassed
AES3 (two channels of digital audio) on 3-pin XLR
48k, 96k or auto tracking to inputs
Sample rate converter can be bypassed
16-, 20- or 24-bit
In, out and through on 5-pin DIN
25-pin D-type (opto isolated)
25-pin D-type (opto isolated)
AES50 (24 channels of bi-directional digital audio) on
Ethercon XLR
AES50 (24 channels of bi-directional digital audio) on
Ethercon XLR providing dual redundant back up of
channels
