Midas PRO6 Owner's Manual page 309

Master controls, solo/mute and fader
Mute, solo and safes
This section contains the MUTE and SOLO buttons, and three safe LEDs (mute safe,
auto safe and fader safe).
1
2
1
MUTE button, mutes all post-processing signals
exiting the channel. In addition to scene recall, it can
also be remotely muted from the auto-mute masters.
2
SOLO button, activates signal routing to the
monitor A section of the control centre by sending the
input channel signal to PFL mono and AFL stereo buses.
The solo system is auto-cancelling, so that each new
solo cancels the last one. Input solos override any
active VCA solos.
This button is a latching type. Give a short press to
latch it and a long press to self-connect when it is
released.
3
Solo B button (GUI only), changes the operation of
the SOLO switch so that it routes signals to the monitor
B section of the control centre.
PRO6 Live Audio System
Owner's Manual
1
3
2
283
