Chapter 26: Using Other Devices With
The PRO6
This chapter explains how to use other external devices with the PRO6.

Using multiple digital consoles

SOURCE OR MASTER/SLAVE STATUS.
You can use a PRO6 together with one or more digital consoles, which can be other
Midas digital consoles or indeed any digital console. For example, you can use two
PRO6s together in a dual FOH and MON system. To do this the digital consoles must be
synchronised.
The synchronisation method can be via AES50, AES3 or wordclock. If you are
connecting the digital consoles via DL431 Mic Splitters, you can synchronise using the
splitters themselves using the Mic Splitters' AES50 connections.
Synchronising the consoles
Before you start, choose which Midas digital console you want as master.
For information on external AES50 synchronisation between two Midas digital consoles,
see "External AES50 synchronisation" on page 104.
>> To configure system synchronisation at the consoles
1
Mute the PA at the amplifier/speaker. Refer to the
of this section.
2
On the master Midas digital console, configure it
by choosing home
the GUI and then clicking the "Master" option
under the Master/Slave Status heading (shown
right).
3
Configure a slave Midas digital console by
choosing home
GUI and then selecting the following options:
• Under the Master/Slave Status heading,
• Open the Sync Source drop-down list and select the synchronisation source
Repeat for any other Midas digital consoles. Configure any non-Midas digital
consoles as appropriate.
PRO6 Live Audio System
Owner's Manual
WARNING!
CHANGING THE SYNCHRONISATION CAN RESULT IN LOUD NOISES
FROM THE SYSTEM. ALWAYS MUTE THE PA AT THE
AMPLIFIER/SPEAKER BEFORE CHANGING THE SYNCHRONISATION
Preferences
Preferences
click the "Slave" option.
you want, that is, "Word Clock" or "AES3". If you want to sync using AES50,
choose one of the eight AES50 ports as necessary, for example, "AES50
Port 2".
WARNING
General at
General at the
221
at the beginning
