Setting up the DL351 Modular I/O unit ID

After connecting up your PRO6 network system, you may need to set up the ID of the
DL351 Modular I/O unit, which is done via its control panel (see Figure 5 below). You
only need to do this if the unit is not already configured to the ID you want; there are
four ID numbers available (1 to 4) and the default is ID 1. The unit's ID number is
shown at the end of the bottom line in the default display, for example, the ID of the
unit shown in Figure 5 is "1".
To change the ID number there is no need to switch on the PRO6 Control Centre, as the
procedure can be carried out offline.
Refer to the operator manual for the DL351 Modular I/O if you require more details.
Figure 5: Control panel of the DL351 Modular I/O (showing default display)
>> To set up the ID of the DL351 Modular I/O unit
1
Make sure the DL351 Modular I/O unit is switched on.
2
Press MENU and hold for approximately two
seconds to enter the main menu. You have
entered the main menu when the first option is
displayed.
3
Press the down arrow button
ID option.
4
Press SELECT to go to the "Select ID" screen.
5
Press the down arrow button
option.
6
Press SELECT to choose the ID 2 option.
7
Press MENU to exit menu mode.
Chapter 4: Setting Up The System
to go to the set
to go to the ID 2
