Midas PRO6 Owner's Manual page 459

Inputs
MIC safe
The following diagram details the parameters in the inputs protected by MIC safe.
DL351 Modular I/O
analogue input card
2
4
6
Item
1
2
3
4
5
6
XL8 Live Performance System
Owner's Manual
Mic splitter
channel
1
2
4
2
10
6
1
input channel
overview in GUI
3
channel strip
Control
stage box control
knob*
48V switch
30Hz switch
gain trim control
knob*
Delay control knob
Ø
switch
Line I/O analogue
input channel
1
2
3
7
8
9
4
1
3
5
Configuration
processing area in GUI
channel strip
Parameter
Gain of remote amplifier
48V phantom gain
30Hz filter
Digital input trim
Delay time
Input phase invert on/off
1
2
1/4
Insert processing
area in GUI
channel strip
433
10
