Dynamics (D Zone) - Midas PRO6 Owner's Manual

268

Dynamics (D zone)

The dynamic section — or D zone — controls two dynamic devices present in the input
channel signal path, that is, the compressor and gate. While most D zone controls are
shared between the two dynamic devices, some are device-specific. The GUI treats
both devices independently, the processing area of the one currently displayed in the
channel strip being the one currently selected to the D zone. Swapping between the
two dynamic devices can be done via an input fast strip, the D zone or the GUI (see "To
select a processing area in the GUI channel strip" on page 49). Operating the dynamic
device's ON/[CMP] button activates the device, but also affects the audio.
You can select the source of both the compressor and gate, and also use the side chain
for both. For side chain details, see "Side chain" on page 273.
Compressor
The input channel compressor has four styles — corrective, adaptive, creative and
vintage — which are selectable via the MODE button. Each has a distinctive
appearance in the GUI channel strip. While the dynamic section is addressing the
compressor, all of its controls are enabled except the hold control knob.
1
2
Vintage
10
D zone
3
9
8
7
Adaptive
Creative
11
4
5
6
10
Corrective
7
Chapter 30: Inputs
11
9
4
12
8
6
PRO6 Live Audio System
Owner's Manual
