Navigating to the Patching screen
Channel or Location on GUI
signal type screen area
Matrix output Insert/configuration
channel processing area - direct
input section
Matrix output Insert/configuration
channel processing area - insert
section
Matrix output Insert/configuration
channel processing area - insert
section
Master output Compressor processing
channel area - side chain section
Master output Compressor processing
channel area
Master output Insert/configuration
channel processing area
Master output Insert/configuration
channel processing area - direct
input section
Master output Insert/configuration
channel processing area - insert
section
Master output Insert/configuration
channel processing area - insert
section
Monitors Monitors screen - talk
input section
Monitors Monitors screen -
external talk output
section
Monitors Monitors screen -
talkback input section
Monitors Monitors screen - pfl
direct input section
Monitors Monitors screen - afl
direct input left section
Monitors Monitors screen - afl
direct input right
section
Monitors Monitors screen -
external input L
section
Monitors Monitors screen -
external input R
section
Monitors Monitors screen -
monitor A output L
section
