Assignable audio processing
Mixing control assistance
Resilience

PRO6 general specifications

Sampling frequency
Latency delay
Dynamic range
Maximum voltage gain
Crosstalk at 1kHz
Crosstalk at 10kHz
Fader/pan cut off at 1kHz
Fader/pan cut off at 10kHz
Display screens
LCD switch
Motorised faders
Fader resolution
Encoders
Encoder resolution
Dimensions
Net weight (standard install)
Power requirements
Operating temperature range
Storage temperature range
Appendix B: Technical Specification
8 x assignable stereo effects
(each can be reconfigured to generate 4 additional
GEQs, making a total of 36 available on the control
centre)
8 x auto-mutes
6 x surface population groups
10 x VCA faders
10 x VCA associated population groups
1000-scene snapshot automation
N+1 and fault tolerant modular system with dual
redundant system interconnections
96kHz
<2ms input to master (no compensation)
110dB, 22Hz to 22kHz (no pre-emphasis)
80dB inputs to subgroups and masters
86dB inputs to aux and matrix
-100dB physically adjacent input channels
-100dB physically adjacent input channels
-100dB
-100dB
2 x 15" daylight-viewable colour screens
33 x RGB colour
29 x touch-sensitive
1024 steps
102 x touch-sensitive
512 steps
PRO6 Control Centre: 1300 x 1000 x 400 mm
DL351 I/O Box: 7Ux 410 mm deep
DL371 DSP: 7U x 410 mm deep
Control centre: 120 kg
1 x DL351: 50 kg
1 x DL371: 30 kg
Total: 200 kg
100V to 240V, 50 to 60Hz
+5°C to +40°C
-20°C to +60°C
