332
Miscellaneous digital characteristics
Type
Word clock
Word clock
AES sync
AES sync
External (Ethernet)
Appendix B: Technical Specification
I/O
IN
Accepts TTL level, 96kHz square wave;
impedance 75 ohms
OUT
Provides a TTL level, 96kHz square wave
IN
Accepts a 96kHz digital audio signal con-
forming to AES3 - 2003
OUT
Provides a 96kHz grade II reference signal
conforming to AES3 - 2003
-
Cat 5e, Auto MDIX, 10Mb/s Fast Ethernet
physical layer
Description Notes
Connector
BNC
BNC
XLR
XLR
Ethercon XLR
