Connectors

This section provides the pinouts for the XVME-653/658 connectors. Refer to the EMC
warning at the beginning of this manual before attaching cables.

Serial Port Connectors

Parallel Port Connector

Table 2-13 Serial Port Connector Pinout
COM1
Pin Signal
1 DCD1
2 RXD1
3 TXD1
4 DTR1
5 GND
6 DSR1
7 RTS1
8 CTS1
9 RI1
Table 2-14 Parallel Port Connector Pinout
Pin Signal
1 STROBE
2 PDOUT0
3 PDOUT1
4 PDOUT2
5 PDOUT3
6 PDOUT4
7 PDOUT5
8 PDOUT6
9 PDOUT7
10 PACK
11 PBUSY
12 PE
13 SELECT
COM2
Pin Signal
1 DCD2
2 RXD2
3 TXD2
4 DTR2
5 GND
6 DSR2
7 RTS2
8 CTS2
9 RI2
Pin Signal
14 AUTOFEED
15 PERROR
16 INIT
17 SELIN
18 GND
19 GND
20 GND
21 GND
22 GND
23 GND
24 GND
25 GND
