P4 Connector
P4 connects up to two 2.5" hard drives. Power for the drives is supplied by the connec-
tor.
The IDE controller supports enhanced PIO modes, which reduce the cy-
cle times for 16-bit data transfers to the hard drive. Check with your
drive manual to see if the drive you are using supports these modes. The
higher the PIO mode, the shorter the cycle time. As the IDE cable length
increases, this reduced cycle time can lead to erratic operation. As a re-
sult, it is in your best interest to keep the IDE cable as short as possible.
The PIO modes are selected in the BIOS setup (see p. 3-4). The Auto-
config will attempt to classify the connected drive if the drive supports
the auto ID command. If you experience problems, change the Transfer
Mode: to Standard.
The total cable length must not exceed 18 inches. If two drives are con-
nected, they must be no more than six inches apart.
Table 5-4 XVME-973/1 P4 Connector Pinout
Pin
Signal
1
HDRSTDRV*
2
GND
3
HD7
4
HD8
5
HD6
6
HD9
7
HD5
8
HD10
9
HD4
10
HD11
11
HD3
12
HD12
13
HD2
14
HD13
15
HD1
16
HD14
17
HD0
18
HD15
19
GND
20
NC
21
HDRQ
22
GND
Caution
Caution
Chapter 5 – XVME-973/1 Drive Adapter Module
Pin
Signal
23
DIOW*
24
GND
25
DIOR*
26
GND
27
IORDY
28
ALE
29
HDACK*
30
GND
31
IRQ14
32
IOCS16*
33
DA1
34
NC
35
DA0
36
DA2
37
CS1P*
38
CS3P*
39
IDEATP*
40
GND
41
+5V
42
+5V
43
GND
44
NC
5-5
