Connectors; Pc/104 Connector Pinouts - Xycom XVME-976/202 Manual

Connectors

The following tables contain pinout information for the various XVME-976
connectors:

PC/104 Connector Pinouts

Pin
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
Table 1-1. PC/104 Connector Pinouts
Row A (P3) Row B (P3)
- -
IOCHCK* GND
SD7 RESETDRV
SD6 +5V
SD5 IRQ9
SD4 NC
SD3 DRQ2
SD2 -12V
SD1 NC
SD0 +12V
IOCHRDY NC
AEN SMEMW*
SA19 SMEMR*
SA18 IOW*
SA17 IOR*
SA16 NC
SA15 NC
SA14 DACK1*
SA13 DRQ1
SA12 REF*
SA11 SYSCLK
SA10 IRQ7
SA9 IRQ6
SA8 IRQ5
SA7 IRQ4
SA6 IRQ3
SA5 DACK2
SA4 TC
SA3 ALE
SA2 +5V
SA1 OSC
SA0 GND
GND GND
Chapter 1 – Introduction
Row D (P4) Row C (P4)
GND GND
MEMCS16* SBHE*
IOCS16* LA23
IRQ10 LA22
IRQ11 LA21
IRQ12 LA20
IRQ15 LA19
IRQ14 LA18
NC LA17
NC MEMR*
DACK5* MEMW*
DRQ5 SD8
DACK6* SD9
DRQ6 SD10
NC SD11
NC SD12
+5V SD13
NC SD14
GND SD15
GND NC
