XVME-653/658 Manual

USB Port Connector

VGA Connector

Keyboard Port Connector

2-8
Table 2-15 USB Port Connector Pinout
Pin Signal
1A +5V
2A USBP0-
3A USBP0+
4A GND
1B +5V
2B USBP1-
3B USBP1+
4B GND
Table 2-16 VGA Connector Pinout
Pin Signal
1 RED
2 GREEN
3 BLUE
4 NC
5 GND
6 GND
7 GND
8 GND
9 25MIL_VIDA
10 GND
11 NC
12 LDDCDAT
13 HYSNC
14 VSYNC
15 LDDCCLK
Table 2-17 Keyboard Port Connector Pinout
Pin Signal
1 DATA
2 NC
3 GND
4 +5V
5 CLK
6 NC
