XVME-653/658 Manual
To remove a strip, pull outward on the plastic tab while lifting the end. Loosen one side,
then the other.
A-2
A
B
C
Figure A-1 DRAM Installation
Insert
DRAM module,
angled at about 50°
to the horizontal,
as shown in
top view A
and
as shown in
side view B
Press DRAM
module down
until it snaps
into place,
as shown in
side view C
