Environmental Specifications

Characteristic
Temperature:
Operating (100 cfm airflow)
XVME-653 (Intel 233 MHz Pentium)
XVME-658 (AMD 333 MHz K6-2)
Nonoperating
Vibration:
Frequency
Operating
Nonoperating
Shock: Operating
Nonoperating
Humidity

Hardware Specifications

Characteristic
Power Specifications:
+12V
-12V
+5V:
XVME-653 (Intel 233 MHz Pentium)
XVME-658 (AMD 333 MHz K6-2)
CPU speed: XVME-653
XVME-658
Cache
Ethernet controller
PCI Super VGA Graphics Controller
Serial Ports
Parallel Interface
Onboard memory
Regulatory Compliance
VMEbus Compliance
Complies with VMEbus Specification ANSI/VITA 1–1994
A32/A24/A16:D64/D32/D16/D08(EO) DTB Master
A32/A24/A16:D64/D32/D16/D08(EO) DTB Slave
R(0-3) Bus Requester
Interrupter I(1)-I(7) DYN
IH(1)-IH(7) Interrupt Handler
SYSCLK and SYSRESET Driver
PRI, SGL, RRS Arbiter
RWD, ROR bus release
Form Factor: Double-height, single-width 233 mm x 160 mm (9.2" x 6.3")
Specification
0 to 50°C (32 to 122°F)
0 to 45°C (32 to 113°F)
-45 to 85°C (-49 to 185°F)
5 to 2000 Hz
0.015" (0.38 mm) peak-to-peak displacement
2.5 G (maximum) acceleration
0.030" (0.76 mm) peak-to-peak displacement
5.0 G (maximum) acceleration
30 G peak acceleration, 11 msec duration
50 G peak acceleration, 11 msec duration
20% to 80% RH, noncondensing
Specification
75 mA maximum
24 mA maximum
10.59 A (maximum); 5.87 A (typical)
10.59 A (maximum); 6.5 A (typical)
233 MHz
333 MHz
512 KB pipeline burst cache
Intel 82558 10/100 BaseTX Fast Ethernet; RJ-45
1280 x 1024 maximum resolution, 256 colors; 2 MB VRAM
RS-232C, 16550 compatible (2)
USB (1)
EPP/ECP compatible (1)
Fast-page or EDO DRAM, ECC or parity, up to 256 MB
European Union
Electromagnetic Compatibility - 89/336/EEC
