WARNING
This is a Class A product. In a domestic environment this product may cause radio in-
terference, in which case the user may be required to take adequate measures.
European Union Directive 89/336/EEC requires that this apparatus comply with relevant
ITE EMC standards. EMC compliance demands that this apparatus is installed within a
VME enclosure designed to contain electromagnetic radiation and which will provide
protection for the apparatus with regard to electromagnetic immunity. This enclosure
must be fully shielded. An example of such an enclosure is a Schroff 7U EMC-RFI VME
System chassis, which includes a front cover to complete the enclosure.
The connection of non-shielded equipment interface cables to this equipment will
invalidate European Economic Area (EEA) EMC compliance and may result in
electromagnetic interference and/or susceptibility levels that are in violation of
regulations which apply to the legal operation of this device. It is the responsibility of the
system integrator and/or user to apply the following directions, as well as those in the
user manual, which relate to installation and configuration:
All interface cables should be shielded, both inside and outside of the
VME enclosure. Braid/foil type shields are recommended for serial,
parallel, and SCSI interface cables. Whereas external mouse cables are
not generally shielded, an internal mouse interface cable must either be
shielded or looped (1 turn) through a ferrite bead at the enclosure point of
exit (bulkhead connector). External cable connectors must be metal with
metal backshells and provide 360-degree protection about the interface
wires. The cable shield must be terminated directly to the metal
connector shell; shield ground drain wires alone are not adequate. VME
panel mount connectors that provide interface to external cables (e.g.,
RS-232, SCSI, keyboard, mouse, etc.) must have metal housings and
provide direct connection to the metal VME chassis. Connector ground
drain wires are not adequate.
