Interboard Connector 2 (P3)

This connector provides power through the center pins.
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
Table 2-22 Interboard Connector 2 Pinout
Signal
TCLK
TRST*
TMS
TDO
TDI
PCI-RSVD9A (Pn2-8)
PCI-RSVD10B (Pn2-9)
PCI-RSVD11A (Pn2-10)
PCI-RSVD14A (Pn1-12)
PCI-RSVD14B (Pn1-10)
PCI-RSVD19A (Pn2-17)
PMC-RSVD_Pn2-34
PMC-RSVD_Pn2-52
PMC-RSVD_Pn2-54
PCICLK3
PIRQA*
PIRQB*
PIRQC*
PIRQD*
REQ3*
PCICLK2
REQ1*
GNT3*
PCICLK1
GNT1*
PCIRST*
PCICLK0
GNT0*
REQ0*
REQ2*
AD31
AD30
AD29
AD28
AD27
AD26
AD25
AD24
BE3*
GNT2*
Pin Signal
41 AD23
42 AD22
43 AD21
44 AD20
45 AD19
46 AD18
47 AD17
48 AD16
49 BE2*
50 FRAME*
51 IRDY*
52 TRDY*
53 DEVSEL*
54 STOP*
55 PLOCK*
56 PERR*
57 SDONE
58 SBO*
59 SERR*
60 PAR
61 BE1*
62 AD15
63 AD14
64 AD13
65 AD12
66 AD11
67 AD10
68 AD9
69 AD8
70 BE0*
71 AD7
72 AD6
73 AD5
74 AD4
75 AD3
76 AD2
77 AD1
78 AD0
79 ACK64*
80 REQ64*
