Registers
The XVME-653/658 contains four I/O port registers: 218h, 219h, 233h, and 234h.
Register 218h – Abort/Clear CMOS Port
This register controls the abort toggle switch and allows you to read the CMOS clear
jumper (J17).
Bit
Signal
0
RESERVED
1
RESERVED
2
RESERVED
3
RESERVED
4
ABORT_STS
5
ABORT_CLR
6
RESERVED
7
CLRCMOS
Register 219h – LED/BIOS Port
This register controls the following LEDs and signals.
Bit
LED/Signal
0
FAULT
1
PASS
2
FLB_A18_EN
3*
FLB_A18/reserve2
4
RESERVED
5
BIOS_D0
6
RESERVED
7
RESERVED
A18, along with control ROM/RAM 15-17 are to be used to page the
Flash when FLB_A18_EN is asserted.
Table 2-8 Abort/Clear CMOS Port Register Settings
Reserved
Reserved
Reserved
Reserved
1 = Abort toggle switch caused interrupt
0 = Clear and disable abort
1 = Enable abort
Reads jumper J13
0 = Clear CMOS
1 = CMOS okay
Table 2-9 LED/BIOS Port Register Settings
0 = Fault LED on
1 = Fault LED off
0 = PASS LED off
1 = PASS LED on
1 = Flash write enabled and A18 is controllable
Reads jumper J19 when FLB_A18_EN = 0
Flash BIOS address A18 when FLB_A18_EN = 1
Reserved
1 = Enable UPPER on board BIOS area @D0000
Reserved
Reserved
*Note
Result
Result
Chapter 2 – Installation
R/W
R
R/W
R
R
R/W
R/W
R/W
R/W
R/W
R/W
2-5
